Transport:
* Top-loading proprietary AMR transport mechanism
Operation modes:
* Direct Master I; no digital or analogue filter
* Direct Master II; no digital filter, anti-sin(x)/(x) analogue filter
* Oversampling 2x
* Oversampling 4x
* Upsampling 96 kHz
* Upsampling 192 kHz
Digital Audio Inputs: * 1 x USB interface, 1 X S/P-DIF Interface (shared)
Analogue Outputs: * 1 x RCA; 1 x XLR per channel
Digital Outputs: * 1 X S/P-DIF Interface
Thermionic Electron Valves amplification stage:
* 6H1n-EV fitted
* ECC88, E88CC,7308, Cca, 6DJ8, 6922,
* 6H23n-EV optional
Output voltage (Digital Full Scale): * > 2V
Frequency Response: * 20Hz to 20 kHz +0.0, -0.5dB
Signal-to-noise ratio “A” Weighted: * > 100 dB
Total Harmonic Dist. + Noise (THD+N): * < 0.3%
Dynamic range: * > 90 dB
Channel separation: * > 90 dB
Power Transformer:
* 32 VA Custom EI Transformer (Digital Section)
* 32 VA Custom EI Transformer (Valve Stage)
Power consumption:
* Standby: < 1 W
* Power on: < 45W
Rated voltage: * 100V/120V/230V~AC 50Hz - 60Hz
Colour: * Silver or Black
Dimensions:
* 17.7 in W by 4.7 in H by 14.6 in D
* 45 cm W by 12 cm H by 37 cm D
* 57 cm W by 49 cm H by 25 cm D (shipped)
Weight:
* CD-777: 25.4 lbs / 11.5 kg
* Shipped: 34.2 lbs / 15.5 kg
|
|
